Battery HW-NE-48D200-NP-5U

Model:HW-NE-48D200-NP-5U
Nominal Energy:9600 Wh
Ability:200Ah
Nominal Voltage:48V DC
Charging Voltage:54.0V ± 0.1V (configurable)
Discharge Cut-Off Voltage:42V ± 0.2V
Maximum Charging Current:100A
Maximum Discharge Current:100A
Charging Efficiency:≥98%
Discharge Efficiency:≥100% @ 0.2C, ≥96% @ 0.5C
Life Cycles:≥5000 cycles at 80% DOD, 25°C
Design Life:≥20 years at 25°C
Screen:Front LCD with LED status of charge (SOC) indicators
Communication:RS485 (x2), RS232
BMS Protections:Overvoltage, undervoltage, overcurrent, short circuit, temperature, cell balancing, and anti-theft alarm with gyroscope and buzzer
Charging Temperature Range:0°C ~ 60°C
Discharge Temperature Range:-20°C ~ 60°C
Storage Temperature:-20°C ~ 55°C
Operating Humidity:≤85% RH
Degree of Protection:IP20
Certifications:ISO9001, ISO14001, GB/T28001, CE, ROHS, TUV, UL1640
Cabinet Material:Iron with insulating paint
Dimensions:67cm (length) × 52cm (width) × 35cm (height)
Weight:85kg

TECHNICAL SHEET

MORE INFORMATION

Extended autonomy:With a 200Ah capacity, you can operate for longer periods of time without worrying about power interruptions.
Total control:LCD display and intelligent BMS management system protect against overcharging, deep discharge, short circuits, and more.
Extra security:Built-in anti-theft gyroscope detects physical tampering.
Optimized cost:More than 4,000 charge cycles at 80% DOD reduce the cost per use compared to traditional batteries.
Easy integration:Ideal as a direct replacement for lead-acid batteries in existing systems, without complex modifications.
Consistent performance:Maintains its capacity and power even at high discharge rates and in extreme climates.

TheHW-NE-48D200-NP-5U batteryIt represents an evolution in energy storage, combining high capacity with advanced protection features. It is ideal for projects requiring constant, long-lasting power, from solar installations to telecommunications networks. Its 5U rack-mount design facilitates installation and stacking in critical infrastructure cabinets.

Thanks to its intelligent monitoring system and anti-theft gyroscope, this battery not only offers energy security but also physical security, protecting your investment. Its high cycle rate and low maintenance allow for years of stable operation, drastically reducing operating costs and the risk of failure in critical applications.
