Fiber ASU 4B1 SPAN100m 4KM

Fiber type:Singlemode G.652D
Amount of fibers:4 fibers (1 loose tube, color coded)
Cable diameter:5.0 ± 0.4 mm
Cable weight:28 ± 5 kg/km
Tube material:PBT
Reinforcing member:1.8mm central FRP
Outer cover:Black polyethylene (PE), UV resistant
Tensile strength:Up to 2400 N
Crush resistance:2000 N/100 mm
Minimum bending radius without tension:10 times the diameter of the cable
Operating temperature:-40°C to +70°C
Installation temperature:-20°C to +60°C
Roll length:4 km
Maximum span between posts:100 m
Dimensions:93cm (length) × 64cm (width) × 93cm (height)
Weight:208kg

TECHNICAL SHEET

Reliable outdoor connection:Perfect for overhead installations in homes, offices or network nodes.
Savings on installation:Self-supporting design requires no additional messenger cable.
High resistance:Withstands mechanical stress, UV rays, humidity and temperature changes.
Ideal for short and medium stretches:Protective cover and excellent transmission on stretches of up to 4km.
Easy to handle:Lightweight, compact and with color-coded fibers for quick identification.

HeASU 4B1 SPAN100mIt is the perfect solution for fiber optic installations requiring few strands but maximum reliability. With a single core tube and protected single-mode fibers, this cable guarantees stable, low-maintenance transmission, even in demanding environmental conditions.

Thanks to its self-supporting design, it is easy to install and requires no additional reinforcements, making it a very attractive option for FTTH projects, monitoring networks, or building-to-building links. Its light weight and compact size allow for quick field handling, while its mechanical strength ensures a long service life.

Whether in rural, suburban or urban areas, theASU 4B1offers the perfect balance between efficiency, quality and practicality for your communication networks.
