XFO-EDFASW19dbm - 32 Outputs

Amplifier type:EDFA (Erbium-Doped Fiber Amplifier)
Number of outputs:32 WDM SC/APC outputs
Input wavelength:1545 – 1565 nm
Input power:-5 ~ +10 dBm
Total output power:23 dBm
Noise level:≤ 5 dB
Connectors:SC/APC
Management:Web, SNMP, RS232
Protection:Overload, over temperature, laser failure
Power source:100–240V AC, 50/60Hz
Dimensions:Length: 55 cm, Width: 55 cm, Height: 21 cm
Weight:4kg

TECHNICAL SHEET

Wide and powerful coverage:23dBm total output ensures strong, clear signal transmission over long distances.
Multiple connections:32 WDM SC/APC outputs allow serving more users from a single device.
Advanced monitoring:Web, SNMP and RS232 management for real-time control and remote administration.
Compact and efficient design:1U rack-mountable format, ideal for small technical spaces.
Protected system:Built-in alarms and automatic ventilation for continuous, safe operation.

HeXFO-EDFA FW23dbm-32WDMIt is an indispensable tool for expanding FTTH optical networks, allowing up to 32 users to be connected with a single unit. Thanks to its 23 dBm output power, it ensures a stable, high-quality signal, even in high-demand environments.

Its professional design and remote management features make it ideal for demanding technical environments such as distribution nodes or equipment rooms. It is a robust and scalable solution for operators looking to improve the efficiency and reach of their fiber optic broadband services.
